Features
Circuit board diagnostics and compact tool for your needs
One click trigger, with automatic piston reset upon completion of crimping
180° Swivelling barrel easy access to connections
Dies pin with self-locking, easier to use
Core parts are general utilization and standardization
Ergonomic in-line design for grip, easily work overhead and in tight spacese
Quality for the highest demands
OLED display shows battery percentage, working cycles, fault code,maintenance note
Weight (with battery): 3.6kg
Dimensions: 500x120x75mm

Technical Data
Ram force                   5OKN
Stroke                      14mm
Crimping range              Cu 240mm2/Al 185mm2
Time/work                   2.5-4s(depend on the dia of cable)
Voltage/capacity            18v/2.0Ah
Charging time               Approx.40 mins
Charging voltage            AC 100V~240V;50~60Hz
Package                     Plastic box
Ambient temperature         -10-40℃

Accessories
Crimping dies                 10-16,25-35,50-70,95,120,150,185,240mm2
Battery                       2pcs
Charger                       1pc
Sealing ring of cylinder      1set
Sealing ring of safety valve  lset
