Features
For replaceable dies
Open-type swivel press-fittings
One-button operation concept to control all tool functions
Ergonomic design for easy one-handed operation
Lightweight and easy to operate
Fast crimping cycles, efficient operation
The motor stops quickly
Automatically retreats back to the position after crimping is completed
Manual back-off is possible
LEDs are used for maintenance control, battery charge indication,and indication of data transfer via UsB adapter
Weight (with battery): 1.7Kg

Technical Data
Capacity                0.75-10mm2
Ram force               13KN
Time/work               2s(depend on the dia of cable)
Voltage/capacity        18v/2.5Ah
Charging time           Approx.30 mins
Charging voltage        AC 100V~240V;50~60Hz
Ambient temperature     -10 °C to +40 °C
Package                 Plastic box
