| LHC250 | LHC315 | LHC355 | |
|---|---|---|---|
| Welding Size: | Dn90、 Dn110、 Dn125、 Dn140、 Dn160、 Dn180、 Dn200、 Dn225、 Dn250 | Dn160、 Dn180、 Dn200、Dn225, Dn250、 Dn280、 Dn315 | Dn160、 Dn180、 Dn200、Dn225, Dn250、 Dn280、 Dn315、Dn355 |
| Sealing Deviation: | <=0.3mm | <=0.3mm | <=0.3mm |
| Temperature Control Range: | 0-280°C | 0-280°C | 0-280°C |
| Temperature Error: | ±3°C | ±3°C | ±3°C |
| Operation Pressure of the Hydraulic System | 0-6.3Mpa | 0-6.3Mpa | 0-6.3Mpa |
| Power: | 4.05KW/220V | 5.85KW/220V | 5.85KW/220V |
| Heating Power: | 2.2KW | 4KW | 4KW |
| Cutter Power: | 1.1KW | 1.1KW | 1.1KW |
| Hydraulic Power: | 0.75KW | 0.75KW | 0.75KW |
| G.W./N.W.(Kg) | 65/50 85/70 | 95/80 100/85 | 135/115 125/110 |
| MEAS(cm) | 93×57×55 75x69x72 | 100×64×65 76x69x69 | 100×72×73 75x64x69 |
